Tailoring CAD Projector

Project patterns directly onto fabric

Eliminate paper patterns entirely - project full-scale patterns with a standard projector, then cut along projected lines. The fastest way to work.

Book Free Demo View Features
FashionDot CAD Projector
Projector Required Min. 3000 lumens, standard HDMI
Calibration Time ~10 minutes (one-time)
Accuracy ±2mm after calibration
CAD Features Full pattern making & grading
Pattern Library 1000+ patterns
Warranty 1 year software support
Features

Everything you need, nothing you don't

Designed specifically for the Indian tailoring industry - practical features that make a real difference every day.
Full-Scale Projection
Project patterns at 100% scale onto any flat surface or cutting table. Works with standard projectors from 3000 lumens upward.
1000+ Pattern patterns
Same massive library as our CAD software - project any of 1000+ garment patterns directly without printing.
Real-Time Adjustment
Adjust pattern scale, proportions and measurements live during projection. No reprinting needed for alterations.
Auto Calibration
One-time projector calibration ensures accurate scale every time. No manual measuring or adjustment after setup.
Zero Paper Cost
Eliminate all pattern paper, printing ink and plotter costs. The projector system pays for itself rapidly.
CAD Software Included
Full FashionDot CAD software included. Use for digital pattern making, grading, and projector output in one license.
Specifications

Technical details

Projector RequiredMin. 3000 lumens, standard HDMI
Calibration Time~10 minutes (one-time)
Accuracy±2mm after calibration
CAD FeaturesFull pattern making & grading
Pattern Library1000+ patterns
Warranty1 year software support

Ready to see it in action?

Book a free demo and see the Tailoring CAD Projector Software working live - at your shop, online or at our showroom. No obligation, completely free.

Book Free Demo
FAQ

Common questions

Everything you need to know before making a decision. Can't find your answer? Contact our team directly.

Contact Us
What projector do I need?

Any standard projector with minimum 3000 lumens brightness. We recommend ceiling-mounted installation for best results. FashionDot can advise on compatible projector models.

How accurate is the projection?

After one-time calibration, projection accuracy is ±2mm - sufficient for all tailoring applications. Calibration takes approximately 10 minutes.

Can I still print patterns?

Yes. The CAD software works for both projection and printing/plotting. Use whichever output method suits each job.

Is the projector included in the price?

The software license is priced separately from the projector hardware. We offer bundle packages. Contact us for current pricing.
